Screw Feeder Supplier Price

Product details of the screw feeder supplier

Quick Overview

screw feeder supplier is made of selected good materials and is manufactured based on advanced production technology. It is excellent in performance, high in quality, and long in service life. Now it is widely applied to the vacuum coating industry. The design of Techflow Pack screw feeder supplier is creative and targeted. A strict quality management system ensures that the product maintains the desired level of excellence. screw feeder supplier is widely applicable to the food industry. It can fulfill the manufacturing needs of various types of food, such as production, processing, and packaging. Techflow Pack maintains relationships with a number of prestigious brands around the world.

Product Introduction

The details of screw feeder supplier are presented to you in the following section.

Working principle

Screw conveyor also called Screw feeder or Screw type Bucket Elevator,  is a kind of machinery that uses a motor to drive the screw rotation and push the material to achieve the purpose of conveying. The working principle is that when the screw shaft rotates, due to the gravity of the material and the friction generated by the trough wall, the material can only move forward along the bottom of the conveyor under the push of the blades, as if the nut that cannot be rotated makes translational movement along the rotating screw. The main forward force of the material is the force that comes from the helical blade to move the material up and forward in the tangential direction of the blade when it rotates axially.

In order to make the screw shaft in a more favorable tensile state, the drive device and the discharge port are generally placed at the same end of the conveyor, and the feeding port is placed near the tail of the other end as much as possible. The rotating screw blades move the material and convey it, so that the force of the material not rotating with the screw conveyor blade is the weight of the material itself and the frictional resistance of the screw conveyor casing to the material. The surface type of the blade has solid surface type, belt surface type, blade surface type and other types according to the different materials to be conveyed. The screw shaft of the screw conveyor has thrust bearings at the end of the material movement direction to give the axial reaction force of the screw with the material, and when the length of the machine is long, an intermediate hanging bearing should be added.

Applications

Screw conveyor is applicable of conveying various of powder materials to form a complete set of packaging system. With the level sensor to realize the auto level tracking feeding and controlling.It is the most common feeding device in the powder feeding and powder packaging industry, which can be applied to the quantitative measurement of a variety of powders or fine particles such as flour, coffee powder, milk powder, tapioca flour, seasoning powder, chemical powder and other materials.

12 (3)

11 (3)

13 (3)

Technical Features 01

The structure of whole machine is made by stainless steel material except of motor,in particular the application of GMP,food sanitation certification

Technical Features 02

Using high quality stable vibration motor to avoid the sticky powder products poor fluidity during the working.

Technical Features 03

Separation modular designing for Screw feeding tube and Vibration hopper ensure the running more smoothly.

Technical Features 04

The Level sensor and intelligent control also available to add on to carry on material level control and overload alarm.
